OLED's

LCT OLED

 OLEDs are a flat display technology made by placing a series of organic thin films between two conductive surfaces. When a current is applied, light is emitted. Because OLEDs produce their own light, they do not require a power hungry backlight.

Some advantages of OLEDs are:

  • Ultra-thin, light weight, or flexible.
  • Low power consumption - OLEDs are a better choice for portable devices.
  • Greater brightness - The screens are brighter, and have a wider viewing angle.
  • Better durability - OLEDs are very durable and can operate in a broader temperature range.
We can provide full datasheets and samples for any of the modules listed below. Please call use at (440)232-8590 to talk to one of our applications specialists about your project

Single Color Modules

Product # Diagonal Pixels Available Colors

Mechanical Size (mm)

 		Thickness (mm) Bonding
Blue Green Yellow Panel
Size		 Viewing Area Pixel
Size

Pixel Pitch
L13001
  0.8"

 96x16
◎


  27.6x10.4
  21.1x3.5
  0.2x0.2
  0.22x0.22
  1.65
  COG
L08201
  0.8"

 96x32
◎

◎
27.18x15.36
  19.18x6.86
  0.18x0.18
  0.20x0.20
  2.05
  TAB
L13201
  0.8"

 96x32
◎


27.18x14.88
  19.18x6.38
  0.18x0.18
  0.20x0.20
  1.65
  TAB
L10602
  1.2"

128x32
◎


 37.5x16.6
  29.42X7.98
  0.21X0.23
  0.23X0.25
  1.65
  TAB
L13601
  1.1"
128x32
◎

◎
  32.7x14.5
  27.5x6.86
0.195x0.195
 0.215x0.215
  1.65
  TAB
L09105
  0.8"
96x39
◎

◎
  26.8x16.7
19.372x8.338
0.182x0.182
0.202x0.202
  1.65
  TAB
L09107
  0.8"
96x39
◎

◎
  26.8x16.7
19.372x8.338
0.182x0.182
0.202x0.202
  1.65
  COF
L08701
  0.8"
80x48
◎


  26.0x19.0
 17.58x10.54
  0.20x0.20
  0.22x0.22
  1.65
  TAB
L08501
  0.9"
96x64
◎


  28.0x22.8
 19.18x12.78
  0.18x0.18
  0.20x0.20
  1.65
  TAB
L09201
  1.0"
96x64
◎

◎
 28.74x22.2
  20.14x13.7
  0.19x0.19
  0.21x0.21
  1.65
  TAB
L10002
  1.0"
 96x64
◎

◎
  29.0x25.5
  20.14x13.7
  0.19x0.19
  0.21x0.21
  1.65
  COG
L10005
  1.0"
 96x64
◎
◎
◎
  29.0x25.5
  20.14x13.7
  0.19x0.19
  0.21x0.21
  1.65
  COG
L07603
  1.0 "
96x64
◎
◎
◎
 28.74x22.2
  20.14x13.7
  0.19x0.19
  0.21x0.21
  1.65
  TAB
L08301
  1.0"
128x64
◎

◎
 30.0x20.16
 23.02x11.98
  0.16x0.16
  0.18x0.18
  2.05
  TAB
L08401
  1.2"
128x64
◎

 ◎
  33.0x23.0
 25.58x15.18
  0.18x0.21
  0.20x0.23
  2.05
  TAB
L09702
  2.4"
128x64


◎
  65.5x40.0
 55.01x27.49
  0.4x0.4
  0.43x0.43
  2.05
  TAB
L09401
  1.3"
128x96
◎


  33.5x31.5
 23.02x23.02
  0.16x0.22
  0.18x0.24
  2.05
  TAB



Full Color Modules

Product
#		 Diagonal Pixels Number of Colors

Mechanical Size (mm)

 		Thickness (mm) Bonding
Panel
Size		 Viewing Area Pixel
Size

Pixel Pitch
  L7401
  1.0"
  96x3x64
65k Colors
26.66x20.38
20.135x13.42
0.045x0.19
0.07x0.21
  1.65
  TAB
  L09805
  1.0"
  96x3x64
65k Colors
26.66x25.0
20.147x13.42
 0.057x0.19
0.07x0.21
  1.45
  COG
  L10302
  1.1"
  96x3x96
262k Colors
  28.8x33.0
20.147x20.14
  0.057x0.19
0.07x0.21
  1.45
  COG
  L10401
  1.1"
  96x3x96
262k Colors
  28.8x27.8
20.147x20.14
  0.057x0.19
0.07x0.21
  1.45
  COF
  L10901
  1.3"
128x3x96
262k Colors
  36.0x30.0
26.867x20.14
  0.057x0.19
0.07x0.21
  1.85
  COF
  L09506
  1.5"
128x3x128
262k Colors
  36.0x36.0
26.855x26.86
  0.045x0.19
0.07x0.21
  2.05
  COF
  L10502
  1.5"
128x3x128
262k Colors
  36.0x40.5
26.855x26.86
  0.045x0.19
0.07x0.21
  2.05
  COG

Click on the Speed Quote link on the left to request a quote for an OLED
